| Part Number | Download | Circuit |
ESD(YES/NO) |
VDS(V) |
VGS(V) |
ID(A) |
VGS(TH)(V) |
RDS(mΩ)@VGS(10V Typ) |
RDS(mΩ)@VGS(10V Max) |
RDS(mΩ)@VGS(4.5V Typ) |
RDS(mΩ)@VGS(4.5V Max) |
Package |
| GPT035N06LTH |
 |
 |
No
|
60
|
±20
|
165
|
2.60
|
2.80
|
3.50
|
-
|
-
|
TO-263-2L |
| GPT029N06LTB |
|
 |
No
|
60
|
±20
|
170
|
2
|
2.45
|
2.90
|
-
|
-
|
TO-220-3L-C |
| GPT013N06NNCU |
|
 |
No
|
60
|
±20
|
220
|
2.20
|
1.30
|
1.70
|
-
|
-
|
PDFN5X6-8L |
| GPT020N06NTP |
|
 |
No
|
60
|
±20
|
250
|
2.60
|
2
|
2.70
|
-
|
-
|
TOLL |
| GPT011N06NNC |
|
 |
No
|
60
|
±20
|
278
|
2.90
|
1.10
|
1.40
|
-
|
-
|
PDFN5X6-8L |
| GPT070N08P56 |
|
 |
No
|
80
|
±20
|
90
|
3
|
5
|
7
|
-
|
-
|
PDFN5×6-8L |
| GPT055N08NTF |
|
 |
No
|
80
|
±20
|
105
|
2.70
|
5
|
6.60
|
-
|
-
|
TO-252-2L |
| GPT065N08NTB |
|
 |
No
|
80
|
±20
|
110
|
3
|
5.20
|
6.50
|
-
|
-
|
TO-220-3L-C |
| GPT1933NTB |
|
 |
No
|
80
|
±20
|
120
|
2.60
|
4.70
|
7
|
-
|
-
|
TO-220-3L-C |
| GPT018N08NTH |
|
 |
No
|
80
|
±20
|
275
|
2.90
|
2.10
|
3
|
-
|
-
|
TO-263-2L |
| GPT018N08NTB |
|
 |
No
|
80
|
±20
|
275
|
2.90
|
2.10
|
3
|
-
|
-
|
TO-220-3L-C |
| GPT018N08NTP |
|
 |
No
|
80
|
±20
|
310
|
3
|
1.80
|
2.40
|
-
|
-
|
TOLL |
| GPT010N08NTP |
|
 |
No
|
80
|
±20
|
420
|
2.90
|
1
|
1.30
|
-
|
-
|
TOLL |
| GPT012N08NTP |
|
 |
No
|
80
|
±20
|
340
|
3
|
1.20
|
1.60
|
-
|
-
|
TOLL |
